| Product number | NU175E27TR-1 |
| Product category | High frequency |
| Product Category | 50~<200KHz |
| Center frequency | 175.0KHz±4% |
| Sensitivity | --- |
| Static capacitance | 600pf±20% |
| Resolution | 1mm |
| Aftershock | 600us Max |
| Direction angle (-6dB) | 14±2° |
| Maximum input voltage (pulse) | 400Vp-p |
| Operating temperature | -20℃~+80℃ |
| Storage temperature | -30℃~+85℃ |
| Shell material | Copper shell/ABS |
