| Product number | NU22E100TR-1 |
| Product category | Long-range |
| Product Category | 10~<20M |
| Center frequency | 22.0KHz±2% |
| Sensitivity | -60dB min |
| Static capacitance | 5000pf±20% |
| Resolution | 10mm |
| Direction angle (-6dB) | 14±2° |
| Maximum input voltage (pulse) | 2800Vp-p |
| Operating temperature | -20℃~+80℃ |
| Storage temperature | -40℃~+85℃ |
| Shell material | Stainless steel |
