| Product number | NU40F30TR-TTL-500 |
| Product category | Cylindrical |
| Product Category | Digital output |
| Measuring range | 30~500cm |
| Standard inspection board | 300*300mm |
| Angle | 60° |
| Repeat accuracy | 1% |
| Operating Voltage | 10~30VDC或15~30VDC |
| Temperature drift | 0.3%/℃（Without temperature compensation） |
| Linearity | 1% |
| Response time | 50ms |
| Power consumption | 20ma |
| Sensor frequency | 40KHz |
| Operating temperature | -20℃~+60℃ |
